C4SMH-RJS-CS14QBB2
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red Oval LED
PDF
/
Inventory: 4273
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 10.35mm
Technical
Wavelength - Dominant 621nm
Forward Current-Max 0.05A
Lens Transparency Clear
Millicandela Rating 1040mcd
Luminous Intensity 1.04 cd
Lens Size 4.20mmx3.10mm
Lens Style Oval with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 100 °
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Base Part Number C4SMH
Number of Functions 1
Packing Method AMMO PACK
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 95°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Screen Master?
Packaging Tape & Box (TB)
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
