CL-196HR-CD-T

Citizen
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description TOP FIRING 1.6 X 0.8 X 0.6 RED
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.27544
≥100 USD $0.123728
≥500 USD $0.111742
≥1000 USD $0.091784
≥3000 USD $0.079816
Inventory: 5559
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height (Max) 0.60mm
Width 800μm
Length 1.6mm
Height 600μm

Technical

Wavelength - Dominant 640nm
Millicandela Rating 23mcd
Luminous Intensity 23 mcd
Forward Voltage 1.8V
Lens Size 1.60mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 1.8V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Color Red
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 1.60mm Lx0.80mm W
Series CL-196
Published 2012
Packaging Tape & Reel (TR)

Physical

Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
