HSMY-C280
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HSMY-C280 LED, Yellow, SMD, 20 mA, 2.1 V, 586 nm
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.21648
≥100 USD $0.124696
≥500 USD $0.097574
≥1000 USD $0.089443
Inventory: 12845
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2012
Size / Dimension 1.00mm Lx0.50mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Yellow
Subcategory Visible LEDs
Power Rating 52mW
Packing Method TAPE AND REEL 7"
Max Power Dissipation 52mW
Number of Functions 1
Depth 500μm
Base Part Number HSMY-C280
Case Code (Metric) 1005
Case Code (Imperial) 0402
Number of Elements 1
Configuration Standard
Power Dissipation 52mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 130°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.00mmx0.50mm
Luminous Intensity 8 mcd
Millicandela Rating 8mcd
Lens Transparency Diffused
Wavelength - Peak 589nm
Lens Color White
Reverse Voltage 5V
Wavelength - Dominant 586nm
Dimensions
Height 400μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
