HSMQ-C170
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD InGaN Green n
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.0296
≥1 USD $1.0296
≥10 USD $0.6512
≥100 USD $0.481712
≥500 USD $0.442675
≥1000 USD $0.364558
≥3000 USD $0.346333
Inventory: 1508
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 800μm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 527nm
Forward Voltage-Max 3.9V
Lens Color White
Wavelength - Peak 520nm
Lens Transparency Diffused
Millicandela Rating 145mcd
Luminous Intensity 145 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.4V
Power Dissipation 78mW
Configuration Standard
Case Code (Imperial) 0805
Case Code (Metric) 2012
Base Part Number HSMQ-C170
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 78mW
Subcategory Visible LEDs
Additional Feature SUPPORTS INFRARED
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Published 2004
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
