HSMN-C190
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD InGaN Blue ue
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.6028
≥100 USD $0.39512
≥500 USD $0.311969
≥1000 USD $0.291174
Inventory: 14923
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Blue
Subcategory Visible LEDs
Power Rating 78mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Base Part Number HSMN-C190
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.3V
Viewing Angle 170°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.00mmx0.80mm
Luminous Intensity 35 mcd
Millicandela Rating 35mcd
Lens Transparency Diffused
Wavelength - Peak 468nm
Lens Color White
Forward Voltage-Max 3.9V
Wavelength - Dominant 470nm
Number of LEDs 1
Reverse Voltage-Max 5V
Dimensions
Height 800μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
