HSML-C130
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Orange Diff. 609lm Thin Profile 370lm
PDF
/
Inventory: 3161
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2013
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Color Orange
Additional Feature SUPPORTS INFRARED
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 1.5mm
Reach Compliance Code compliant
Base Part Number HSML-C130
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.94V
Viewing Angle 110°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.15mmx0.80mm
Luminous Intensity 139.0 mcd
Millicandela Rating 139mcd
Lens Transparency Diffused
Wavelength - Peak 612nm
Lens Color White
Forward Current-Max 0.02A
Forward Voltage-Max 2.4V
Overall Height 0.35mm
Wavelength - Dominant 606nm
Reverse Voltage-Max 5V
Dimensions
Height (Max) 0.35mm
Compliance
RoHS Status RoHS Compliant
