HSML-A100-R7PJ1
RoHS
RoHS compliant
RoHS compliantPackage 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD AlInGaP Orange Org
PDF
/
Inventory: 7214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 2.10mm
Technical
Wavelength - Dominant 605nm
Overall Height 1.9mm
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 609nm
Lens Transparency Clear
Luminous Intensity 212.5 mcd
Lens Size 2.20mm Dia
Lens Style Round with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Operating Temperature (Min) -55°C
Operating Temperature (Max) 100°C
Base Part Number HSML-A100
Reach Compliance Code compliant
Terminal Pitch 3mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Color Orange
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 3.20mm Lx2.80mm W
Published 2010
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 2-PLCC
Mounting Type Surface Mount
