HSMK-A100-S00J1
RoHS
/
Package 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD InGaN Cyan yan
PDF
/
Inventory: 4817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-PLCC
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 3.20mm Lx2.80mm W
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -55°C
Color Cyan
Additional Feature HIGH RELIABILITY
Power Rating 114mW
Voltage - Rated DC 3.4V
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 3mm
Base Part Number HSMK-A100
Configuration Standard
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Flat Top
Lens Size 2.20mm Dia
Luminous Intensity 280 mcd
Illumination Color Green
Lens Transparency Clear
Wavelength - Peak 502nm
Lens Color Colorless
Overall Height 1.9mm
Wavelength - Dominant 505nm
Compliance
RoHS Status RoHS Compliant
