HSMG-C660
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN DIFF 2SMD R/A
PDF
/
Inventory: 1132
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 1.00mm
Technical
Wavelength - Dominant 572nm
Overall Height 1mm
Forward Current-Max 0.025A
Lens Color White
Wavelength - Peak 570nm
Lens Transparency Diffused
Millicandela Rating 9mcd
Luminous Intensity 9.0 mcd
Lens Size 2.00mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 155°
Voltage - Forward (Vf) (Typ) 2.2V
Configuration Standard
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Base Part Number HSMG-C660
Terminal Pitch 3.5mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
HTS Code 8541.40.20.00
Additional Feature SUPPORTS INFRARED
Color Green
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Size / Dimension 3.00mm Lx2.00mm W
Published 2001
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
