HSMG-A100-L02J1

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description BROADCOM LIMITED - HSMG-A100-L02J1 - LED, SMD, PLCC2, GREEN
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.3124
≥100 USD $0.179344
≥500 USD $0.140386
Inventory: 22626
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 18 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-PLCC
Number of Pins 2

Technical

Packaging Tape & Reel (TR)
Published 2000
Size / Dimension 3.20mm Lx2.80mm W
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Max Operating Temperature 100°C
Min Operating Temperature -55°C
Color Yellow-Green
Power Rating 63mW
Base Part Number HSMG-A100
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Flat Top
Lens Size 2.20mm Dia
Luminous Intensity 18 mcd
Illumination Color Green
Lens Transparency Clear
Wavelength - Peak 558nm
Lens Color Colorless
Wavelength - Dominant 560nm
Number of LEDs 1

Dimensions

Height 2.1mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
