HSMF-C655
RoHS
/
Package 1210 (3225 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED Bi-Color Green/Red 570nm/639nm 4-Pin Chip LED T/R
PDF
/
Buying Options
Total Price: USD $0.06
Unit Price: USD $0.05605
≥1 USD $0.05605
≥10 USD $0.0456
≥100 USD $0.04465
≥500 USD $0.04275
≥1000 USD $0.0418
Inventory: 8206
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Surface Mount YES
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Size / Dimension 3.20mm Lx2.70mm W
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Color HIGH EFFICIENCY RED/GREEN
HTS Code 8541.40.20.00
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 3.5mm
Base Part Number HSMF-C65
Operating Temperature (Max) 80°C
Operating Temperature (Min) -25°C
Configuration SEPARATE, 2 ELEMENTS
Viewing Angle 155 deg
Optoelectronic Device Type DUAL COLOR LED
Luminous Intensity 5.0/9.0 mcd
Lens Type DIFFUSED
Forward Current-Max 0.025A
Overall Height 1.1mm
Peak Wavelength 639/570 nm
Dimensions
Height (Max) 1.10mm
Compliance
RoHS Status Non-RoHS Compliant
