HSMF-C113
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
AVAGO TECHNOLOGIES - HSMF-C113 - LED, SMD, RED/YEL-GRN/BLUE
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $0.77968
≥100 USD $0.577104
≥500 USD $0.530341
≥1000 USD $0.436753
Inventory: 1186
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 1mm
Technical
Wavelength - Dominant 626nm Red 572nm Green 470nm Blue
Reverse Voltage 5V
Lens Color White
Wavelength - Peak 637nm Red 570nm Green 468nm Blue
Lens Transparency Diffused
Millicandela Rating 80mcd Red, 50mcd Green, 60mcd Blue
Luminous Intensity 60 mcd
Lens Size 2.10mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA Red 20mA Green 20mA Blue
Forward Current 20mA
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 120° Red, 125° Green, 125° Blue
Voltage - Forward (Vf) (Typ) 1.9V Red 2V Green 3.4V Blue
Configuration Common Anode
Number of Elements 3
Base Part Number HSMF-C11
Depth 1mm
Number of Functions 1
Packing Method TR, 7 INCH
Power Rating 78mW
Subcategory Visible LEDs
Color Red, Green, Blue (RGB)
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 2.50mm Lx1.00mm W
Published 2004
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
