HSMD-C170
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE DIFFUSED CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.23232
≥100 USD $0.155144
≥500 USD $0.107325
≥1000 USD $0.089434
≥3000 USD $0.080494
Inventory: 70775
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 800μm
Technical
Wavelength - Dominant 604nm
Reverse Voltage 5V
Lens Color White
Wavelength - Peak 605nm
Lens Transparency Diffused
Millicandela Rating 8mcd
Luminous Intensity 8 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 170°
Power Dissipation 52mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0805
Case Code (Metric) 2012
Base Part Number HSMD-C170
Depth 1.25mm
Number of Functions 1
Max Power Dissipation 52mW
Packing Method TAPE AND REEL 7"
Voltage - Rated DC 2.2V
Power Rating 52mW
Subcategory Visible LEDs
Additional Feature SUPPORTS INFRARED
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 2.00mm Lx1.25mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
