HSMD-C110
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Orange 605nm 2-Pin Chip LED T/R
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.3036
≥100 USD $0.174592
≥500 USD $0.136646
Inventory: 1156
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, No Lead
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2012
Size / Dimension 3.20mm Lx1.50mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Additional Feature SIDE VIEW, SUPPORTS INFRARED
Subcategory Visible LEDs
Power Rating 65mW
Voltage - Rated DC 2.2V
Packing Method TAPE AND REEL 7"
Max Power Dissipation 65mW
Number of Functions 1
Terminal Pitch 3.5mm
Depth 1mm
Base Part Number HSMD-C110
Number of Elements 1
Configuration Standard
Power Dissipation 78mW
Viewing Angle 130°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Domed Top
Lens Size 2.00mmx1.00mm
Luminous Intensity 8 mcd
Millicandela Rating 8mcd
Lens Transparency Clear
Wavelength - Peak 605nm
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 604nm
Dimensions
Height 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
