HSMC-S690
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD AlInGaP Red Red
PDF
/
Inventory: 3354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height 700μm
Technical
Wavelength - Dominant 626nm
Wavelength - Peak 630nm
Lens Transparency Diffused
Millicandela Rating 50mcd
Luminous Intensity 50 mcd
Lens Size 1.20mmx0.80mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 165°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Terminal Pitch 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL
Power Rating 81mW
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Size / Dimension 1.60mm Lx0.80mm W
Series SunPower
Published 1998
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
