HSMC-C265
RoHS
RoHS compliant
RoHS compliantPackage 1305 (3412 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED 1305 SMD REV
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.33264
≥100 USD $0.1914
≥500 USD $0.149829
Inventory: 21391
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 1.1mm
Technical
Wavelength - Dominant 626nm
Reverse Voltage 5V
Lens Color White
Wavelength - Peak 637nm
Lens Transparency Diffused
Millicandela Rating 75mcd
Luminous Intensity 75 mcd
Lens Size 1.25mmx1.20mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 130°
Voltage - Forward (Vf) (Typ) 1.9V
Power Dissipation 60mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 1305
Case Code (Metric) 3412
Base Part Number HSMC-C265
Depth 3.4mm
Terminal Pitch 3.7mm
Number of Functions 1
Max Power Dissipation 60mW
Packing Method TAPE AND REEL 7"
Power Rating 60mW
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 3.40mm Lx1.25mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1305 (3412 Metric)
Mounting Type Surface Mount, Bottom Entry
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
