HSMC-A431-X90M1
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM - HSMC-A431-X90M1 - LED, Red, SMD, PLCC-4, 50 mA, 2.2 V, 626 nm
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.39248
≥100 USD $0.256872
≥500 USD $0.202778
Inventory: 299
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-PLCC
Number of Pins 4
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 3.20mm Lx2.80mm W
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Pure Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
Subcategory Visible LEDs
Power Rating 180mW
Max Power Dissipation 180mW
Number of Functions 1
Depth 3.2mm
Base Part Number HSMC-A431
Number of Elements 1
Configuration Standard
Power Dissipation 180mW
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 30°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 50mA
Lens Style Round with Domed Top
Luminous Intensity 4 cd
Millicandela Rating 4000mcd
Lens Transparency Clear
Wavelength - Peak 635nm
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 626nm
Dimensions
Height 3.87mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
