HSMB-C172
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Blue aN Blue
PDF
/
Inventory: 1470
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.80mm
Technical
Luminous Intensity-Min 170 cd
Reverse Voltage-Max 5V
Wavelength - Dominant 462nm
Overall Height 0.8mm
Forward Voltage-Max 4.6V
Forward Current-Max 0.01A
Lens Color White
Wavelength - Peak 428nm
Lens Transparency Diffused
Millicandela Rating 3mcd
Luminous Intensity 3.0 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 170°
Voltage - Forward (Vf) (Typ) 4V
Configuration Standard
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Reach Compliance Code compliant
Terminal Pitch 2.1mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Blue
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Size / Dimension 2.00mm Lx1.25mm W
Published 2008
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
