HSMA-C265
RoHS
RoHS compliant
RoHS compliantPackage 1305 (3412 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HSMA-C265 LED, Amber, SMD, 1.2mm x 1.25mm, 20 mA, 1.9 V, 592 nm
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.33264
≥100 USD $0.191488
≥500 USD $0.149855
Inventory: 47974
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Amber
Subcategory Visible LEDs
Power Rating 60mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 3.7mm
Depth 3.4mm
Base Part Number HSMA-C265
Case Code (Metric) 3412
Case Code (Imperial) 1305
Number of Elements 1
Configuration Standard
Power Dissipation 60mW
Voltage - Forward (Vf) (Typ) 1.9V
Viewing Angle 150°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.25mmx1.20mm
Luminous Intensity 75 mcd
Illumination Color Orange
Lens Transparency Diffused
Wavelength - Peak 595nm
Lens Color White
Luminous Flux 480 lm
Reverse Voltage 5V
Part Status Active
JESD-609 Code e4
Size / Dimension 3.40mm Lx1.25mm W
Published 2010
Packaging Tape & Reel (TR)
Wavelength - Dominant 592nm
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1305 (3412 Metric)
Mounting Type Surface Mount, Bottom Entry
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
Dimensions
Height 1.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
