HSMA-C150
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Amber 595nm 2-Pin Chip LED T/R
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.33792
≥100 USD $0.223608
≥500 USD $0.172621
Inventory: 8682
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 1.1mm
Technical
Wavelength - Dominant 592nm
Reverse Voltage 5V
Lens Color White
Wavelength - Peak 595nm
Lens Transparency Diffused
Illumination Color Orange
Luminous Intensity 90 mcd
Lens Size 2.00mmx1.60mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 170°
Voltage - Forward (Vf) (Typ) 1.9V
Power Dissipation 60mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 1206
Case Code (Metric) 3216
Base Part Number HSMA-C150
Depth 1.6mm
Terminal Pitch 3.5mm
Number of Functions 1
Max Power Dissipation 60mW
Packing Method TAPE AND REEL 7"
Power Rating 60mW
Subcategory Visible LEDs
Additional Feature SUPPORTS INFRARED
Color Amber
Min Operating Temperature -30°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 3.20mm Lx1.60mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 13 Weeks
