HSMA-A100-Q00H1
RoHS
RoHS compliant
RoHS compliantPackage 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Amber 592nm 2-Pin PLCC T/R
PDF
/
Inventory: 3314
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Bottom Entry
Package / Case 2-PLCC
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2016
Size / Dimension 3.20mm Lx2.80mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Terminal Finish Matte Tin (Sn)
Color Amber
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.4V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Flat Top
Luminous Intensity 5 mcd
Lens Transparency Clear
Wavelength - Peak 592nm
Lens Color Colorless
Wavelength - Dominant 590nm
Number of LEDs 1
Dimensions
Height 2.1mm
Compliance
RoHS Status ROHS3 Compliant
