HLMP-S501-D0002

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description LED Uni-Color Green 565nm 2-Pin T/R
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.576981
≥1 USD $0.576981
Inventory: 1191
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Shape RECTANGULAR

Technical

Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Depth 2.23mm
Base Part Number HLMP-S
Number of Elements 1
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 110°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 5.06mmx2.11mm
Luminous Intensity 8 mcd
Millicandela Rating 8mcd
Lens Transparency Diffused
Wavelength - Peak 565nm
Forward Voltage-Max 3V
Wavelength - Dominant 569nm
Reverse Voltage-Max 5V

Dimensions

Height 8mm
Length 5.46mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
