HLMP-P156-EG011
RoHS
/
Package 2-SMD, Gull Wing
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Poly FTop Red
PDF
/
Buying Options
Total Price: USD $9.35
Unit Price: USD $9.3499
≥1 USD $9.3499
≥10 USD $7.67125
≥100 USD $7.43185
≥500 USD $7.19245
≥1000 USD $6.9521
Inventory: 1269
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 2.44mm
Technical
T-code T-3/4
Wavelength - Dominant 644nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 654nm
Lens Transparency Clear
Luminous Intensity 2 mcd
Lens Size 1.78mm Dia
Lens Style Round with Flat Top
Current - Test 0.5mA
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 75°
Voltage - Forward (Vf) (Typ) 1.6V
Power Dissipation 100mW
Configuration Standard
Number of Elements 1
Base Part Number HLMP-P156
Depth 2.21mm
Number of Functions 1
Max Power Dissipation 100mW
Packing Method TAPE AND REEL 7"
Power Rating 100mW
Subcategory Visible LEDs
Color Red
Min Operating Temperature -55°C
Max Operating Temperature 100°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 2.09mm Lx2.21mm W
Published 2016
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
