HLMP-P105-NP000
RoHS
RoHS compliant
RoHS compliantPackage Axial, Flat Leads
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Poly FTop Red
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.919128
≥1 USD $0.919128
Inventory: 24010
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount, Through Hole
Mounting Type Through Hole, Axial
Package / Case Axial, Flat Leads
Number of Pins 2
Shape CYLINDRICAL
Technical
Packaging Bulk
Size / Dimension 2.09mm Lx2.21mm W
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature TTL COMPATIBLE
Subcategory Visible LEDs
Number of Functions 1
Base Part Number HLMP-P105
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.8V
Viewing Angle 125°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Flat Top
Lens Size 1.78mm Dia
Luminous Intensity 30 mcd
Millicandela Rating 52.5mcd
Lens Transparency Clear
Wavelength - Peak 645nm
Lens Color Colorless
Wavelength - Dominant 637nm
Number of LEDs 1
T-code T-3/4
Reverse Voltage-Max 5V
Dimensions
Height 2.44mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
