HLMP-LM11-NR000
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Green 50x100deg 0X100deg
PDF
/
Inventory: 6260
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 9.98mm
Technical
Reverse Voltage-Max 5V
Wavelength - Dominant 525nm
Overall Height 6.3mm
Forward Voltage-Max 4V
Forward Current-Max 0.03A
Wavelength - Peak 520nm
Lens Transparency Clear
Millicandela Rating 1290mcd
Luminous Intensity 1290.0 mcd
Lens Size 3.70mm
Lens Style Oval with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 50 deg
Voltage - Forward (Vf) (Typ) 3.8V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 80°C
Base Part Number HLMP-LM11
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 1
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Green
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2006
Packaging Bulk
Physical
Surface Mount NO
Package / Case Radial
Mounting Type Through Hole
