HLMP-HD30-SV000
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red 40x100deg 2 40X100deg
PDF
/
Inventory: 6564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Packaging Bulk
Published 2006
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Base Part Number HLMP-H*30
Lead Pitch 2.54mm
Lead Length 25mm
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.84V
Viewing Angle 100°, 40°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 70mA
Lens Style Oval with Domed Top
Lens Size 5.20mmx3.80mm
Luminous Intensity 3.309 cd
Millicandela Rating 3309mcd
Wavelength - Peak 638nm
Forward Voltage-Max 3.25V
Wavelength - Dominant 626nm
Outside Diameter 5 mm
Reverse Voltage-Max 5V
Dimensions
Diameter 5mm
Height 7mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
