HLMP-EL2A-XYKDD
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HLMP-EL2A-XYKDD LED, Amber, Through Hole, T-1 3/4 (5mm), 20 mA, 2.1 V, 594.5 nm
PDF
/
Inventory: 2958
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Technical
Packaging Tape & Box (TB)
Published 2008
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Amber
Depth 5.8mm
Base Part Number HLMP-EL2A
Number of Elements 1
Configuration Standard
Power Dissipation 120mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 23°
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 12 cd
Millicandela Rating 9600mcd
Illumination Color Orange
Lens Transparency Clear
Wavelength - Peak 594nm
Lens Color Colorless
Luminous Flux 2.1 lm
Reverse Voltage 5V
Wavelength - Dominant 590nm
Dimensions
Height 8.91mm
Length 5.8mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
