HLMP-EL25-SUS00
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Amber, 592nm 23 Deg, 4200mcd(max)
PDF
/
Inventory: 7146
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Published 2009
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Amber
HTS Code 8541.40.20.00
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Base Part Number HLMP-EL25
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.3V
Viewing Angle 23°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 3050.0 mcd
Millicandela Rating 3050mcd
Lens Transparency Clear
Wavelength - Peak 594nm
Lens Color Colorless
Forward Current-Max 0.05A
Overall Height 8.71mm
Wavelength - Dominant 592nm
Dimensions
Height (Max) 8.91mm
Compliance
RoHS Status RoHS Compliant
