HLMP-EH24-QT000
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red-Orange, 615nm 23 Deg, 3200mcd(max)
PDF
/
Inventory: 8252
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Subcategory Visible LEDs
Number of Functions 1
Base Part Number HLMP-EH24
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.94V
Viewing Angle 23°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 2.175 cd
Millicandela Rating 2175mcd
Illumination Color Orange
Lens Transparency Clear
Wavelength - Peak 621nm
Lens Color Colorless
Forward Current-Max 0.05A
Luminous Flux 500 mlm
Wavelength - Dominant 615nm
Number of LEDs 1
Additional Feature HIGH RELIABILITY
Color Red
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
JESD-609 Code e3
Packaging Bulk
Dimensions
Diameter 5mm
Height 8.91mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
