HLMP-CW47-QRBDD
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED COOL WHITE DIFF T-1 3/4 T/H
PDF
/
Inventory: 6542
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Tape & Box (TB)
Published 2006
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color White
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Base Part Number HLMP-CW47
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 50°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 1525.0 mcd
Millicandela Rating 1525mcd
Lens Transparency Diffused
Forward Current-Max 0.03A
Forward Voltage-Max 4V
Overall Height 8.71mm
Reverse Voltage-Max 5V
Dimensions
Height (Max) 12.23mm
Compliance
RoHS Status RoHS Compliant
