HLMP-CW46-STBDD
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Round with Domed Top HLMP-CW46 SINGLE COLOR LED White LED Indication Discrete 3.2V 20mA 2550mcd 50°
PDF
/
Inventory: 8280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Tape & Box (TB)
Published 2006
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color White
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Base Part Number HLMP-CW46
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 50°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 2550.0 mcd
Millicandela Rating 2550mcd
Lens Transparency Diffused
Forward Current-Max 0.03A
Overall Height 8.71mm
Dimensions
Height (Max) 8.91mm
Compliance
RoHS Status RoHS Compliant
