HLMP-CW46-ST0DD

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - Through Hole White 50deg 50deg
PDF
/
Inventory: 1656
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height (Max) 8.91mm

Technical

Overall Height 8.71mm
Forward Current-Max 0.03A
Lens Transparency Diffused
Millicandela Rating 2550mcd
Luminous Intensity 2550.0 mcd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 50°
Voltage - Forward (Vf) (Typ) 3.2V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Base Part Number HLMP-CW46
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 1
Packing Method AMMO PACK
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Color White
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2006
Packaging Tape & Box (TB)

Physical

Surface Mount NO
Package / Case Radial
Mounting Type Through Hole
