HLMP-CM29-WZ0DD

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description LED GREEN CLEAR 5MM ROUND T/H
PDF
/
Inventory: 10025
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case Radial
Surface Mount NO

Technical

Packaging Tape & Box (TB)
Published 2005
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Color Green
HTS Code 8541.40.20.00
Packing Method AMMO PACK
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Base Part Number HLMP-CM
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 23°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 9300.0 mcd
Millicandela Rating 9300mcd
Lens Transparency Clear
Wavelength - Peak 523nm
Lens Color Colorless
Forward Current-Max 0.03A
Overall Height 8.71mm
Wavelength - Dominant 530nm

Dimensions

Height (Max) 12.92mm

Compliance

RoHS Status RoHS Compliant
