HLMP-CE24-UXC00
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Cyan 23 deg 23deg
PDF
/
Inventory: 3170
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Technical
Packaging Bulk
Published 2007
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Cyan
HTS Code 8541.40.20.00
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Base Part Number HLMP-CE
Operating Temperature (Max) 80°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 23°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 6250.0 mcd
Millicandela Rating 6250mcd
Lens Transparency Clear
Wavelength - Peak 502nm
Lens Color Colorless
Forward Current-Max 0.03A
Overall Height 8.71mm
Wavelength - Dominant 505nm
Dimensions
Height (Max) 12.65mm
Compliance
RoHS Status RoHS Compliant
