HLMP-BL16-PSRYY
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Lamp 5mm AlInGaP2 Am b 30X70deg
PDF
/
Inventory: 9083
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 8.91mm
Technical
T-code T-1 3/4
Wavelength - Dominant 592nm
Overall Height 8.71mm
Forward Current-Max 0.05A
Wavelength - Peak 594nm
Lens Transparency Clear
Millicandela Rating 1690mcd
Luminous Intensity 1690.0 mcd
Lens Size 5.00mm
Lens Style Oval with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 70°, 35°
Voltage - Forward (Vf) (Typ) 2.3V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Base Part Number HLMP-BL
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 1
HTS Code 8541.40.20.00
Color Amber
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2008
Packaging Bulk
Physical
Surface Mount NO
Package / Case Radial
Mounting Type Through Hole
