HLMP-AG75-120DD
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HLMP-AG75-120DD LED, Red, Through Hole, T-1 3/4 (5mm), 20 mA, 2.1 V, 626 nm
PDF
/
Inventory: 7840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 12.2mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 626nm
Forward Voltage-Max 2.4V
Wavelength - Peak 634nm
Lens Transparency Diffused
Millicandela Rating 3550mcd
Luminous Intensity 4.2 cd
Lens Size 5.30mmx3.90mm
Lens Style Oval with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 70°, 35°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Operating Temperature (Min) -40°C
Base Part Number HLMP-AG
Subcategory Visible LEDs
Color Red
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tape & Box (TB)
Physical
Number of Pins 5
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
