HLMP-AG71-Z20DD
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED 5MM OVAL T/H
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.723549
≥1 USD $0.723549
≥10 USD $0.682596
≥100 USD $0.643963
≥500 USD $0.607504
≥1000 USD $0.573117
Inventory: 1184
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 12.55mm
Technical
Luminous Intensity-Min 2.4 cd
Reverse Voltage-Max 5V
Wavelength - Dominant 626nm
Overall Height 8.7mm
Forward Voltage-Max 2.4V
Forward Current-Max 0.05A
Wavelength - Peak 634nm
Lens Transparency Diffused
Lens Size 5.20mmx3.80mm
Lens Style Oval with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 30° x 70°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Red
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 5.40mm Lx4.00mm W
Series HLMP-AG71
Packaging Tape & Box (TB)
Physical
Package / Case Radial
Mounting Type Through Hole
Supply Chain
Factory Lead Time 16 Weeks
