HLMP-6505-L001S

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Axial, Right Angle Bend (2.54mm Center)
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - Through Hole Poly Dome Green
PDF
/
Inventory: 1847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height (Max) 2.92mm

Technical

Reverse Voltage-Max 5V
T-code T-3/4
Wavelength - Dominant 569nm
Overall Height 2.92mm
Forward Voltage-Max 2.7V
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 565nm
Lens Transparency Clear
Millicandela Rating 40mcd
Luminous Intensity 40.0 mcd
Lens Size 1.78mm Dia
Lens Style Round with Domed Top
Current - Test 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 28°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Base Part Number HLMP-6505
Reach Compliance Code compliant
Terminal Pitch 2.54mm
Number of Functions 1
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature TTL COMPATIBLE
Color Green
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 2.08mm Lx2.21mm W
Packaging Bulk

Physical

Mounting Feature AXIAL MOUNT
Surface Mount NO
Package / Case Axial, Right Angle Bend (2.54mm Center)
Mounting Type Through Hole
