HLMP-6400
RoHS
RoHS compliant
RoHS compliantPackage Axial, Flat Leads
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HLMP-6400 LED, Yellow, Through Hole, 1.9mm, 10 mA, 2 V, 585 nm
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6192
≥1 USD $1.6192
≥10 USD $1.02696
≥100 USD $0.75988
≥500 USD $0.698298
≥1000 USD $0.575062
≥3000 USD $0.546313
Inventory: 8362
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 2.92mm
Diameter 1.8mm
Technical
T-code T-3/4
Wavelength - Dominant 585nm
Reverse Voltage 5V
Wavelength - Peak 583nm
Lens Transparency Diffused
Millicandela Rating 9mcd
Luminous Intensity 9 mcd
Lens Size 1.91mm Dia
Lens Style Round with Domed Top
Forward Current 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 90°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Number of Elements 1
Lead Length 11mm
Base Part Number HLMP-6400
Depth 2.34mm
Number of Functions 1
Subcategory Visible LEDs
Additional Feature TTL COMPATIBLE
Color Yellow
Min Operating Temperature -55°C
Max Operating Temperature 100°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e3
Size / Dimension 2.08mm Lx2.21mm W
Published 2008
Packaging Bulk
Physical
Number of Pins 2
Package / Case Axial, Flat Leads
Mounting Type Through Hole, Axial
Mount Axial, PCB, Surface Mount, Through Hole
Supply Chain
Factory Lead Time 13 Weeks
