HLMP-6300-F0031
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Z-Bend
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED Z-BEND SMD
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.6936
≥1 USD $3.6936
≥10 USD $3.0305
≥100 USD $2.9355
≥500 USD $2.84145
≥1000 USD $2.74645
Inventory: 1698
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, Z-Bend
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Size / Dimension 2.08mm Lx2.21mm W
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature TTL COMPATIBLE
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Depth 2.21mm
Base Part Number HLMP-6300
Number of Elements 1
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.8V
Viewing Angle 90°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 10mA
Lens Style Round with Domed Top
Lens Size 1.78mm Dia
Luminous Intensity 10 mcd
Lens Transparency Diffused
Wavelength - Peak 635nm
Reverse Voltage 5V
Forward Voltage-Max 3V
Wavelength - Dominant 626nm
T-code T-3/4
Dimensions
Height 2.92mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
