HLMP-3680
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED HLMP-3680 LED, Green, Through Hole, T-1 3/4 (5mm), 10 mA, 5 V, 569 nm
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
≥10 USD $0.44528
≥100 USD $0.291632
≥500 USD $0.270266
Inventory: 1244
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 6.1mm
Height 9.19mm
Diameter 5mm
Technical
Wavelength - Dominant 569nm
Reverse Voltage 5V
Wavelength - Peak 565nm
Lens Transparency Diffused
Millicandela Rating 1.6mcd
Luminous Intensity 1.6 mcd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Forward Current 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 60°
Configuration Standard
Number of Elements 1
Lead Length 23mm
Base Part Number HLMP-3680
Depth 6.1mm
Number of Functions 1
Subcategory Visible LEDs
Additional Feature TTL COMPATIBLE
Color Green
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2007
Packaging Bulk
Physical
Shape Round
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
