HLMP-1321-G0002
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED Uni-Color Red 635nm 2-Pin T-1 T/R
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4752
≥1 USD $0.4752
≥10 USD $0.29128
≥100 USD $0.167464
Inventory: 23279
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 3.43mm
Height 6.35mm
Diameter 3mm
Technical
T-code T-1
Wavelength - Dominant 626nm
Reverse Voltage 5V
Wavelength - Peak 635nm
Lens Transparency Clear
Luminous Intensity 30 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Current - Test 10mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 45°
Voltage - Forward (Vf) (Typ) 1.9V
Power Dissipation 135mW
Configuration Standard
Number of Elements 1
Base Part Number HLMP-1321
Depth 3.43mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
