HLMP-0504-B0000
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Lamp Green
PDF
/
Inventory: 2861
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Bulk
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 100°C
Min Operating Temperature -20°C
Color Green
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
Subcategory Visible LEDs
Number of Functions 1
Depth 2.54mm
Base Part Number HLMP-0504
Number of Elements 1
Configuration Standard
Power Dissipation 135mW
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 100°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 7.31mmx2.35mm
Luminous Intensity 1.6 mcd
Lens Transparency Diffused
Wavelength - Peak 565nm
Reverse Breakdown Voltage 5V
Reverse Voltage 5V
Forward Voltage-Max 3V
Wavelength - Dominant 569nm
Dimensions
Height 8mm
Length 7.62mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
