HLMA-PL00-QRX11

Broadcom Limited
RoHS
/
Package 2-SMD, Gull Wing
Category Optoelectronics / LED Indication - Discrete
Description LED Uni-Color Amber 592nm 2-Pin T/R
PDF
/
Inventory: 3981
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height 2.44mm

Technical

Reverse Voltage-Max 5V
T-code T-3/4
Number of LEDs 1
Wavelength - Dominant 590nm
Luminous Flux 250 mlm
Lens Color Colorless
Wavelength - Peak 592nm
Lens Transparency Clear
Illumination Color Orange
Luminous Intensity 131.5 mcd
Lens Size 1.78mm Dia
Lens Style Round with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 125°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Base Part Number HLMA-PL00
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 120mW
Subcategory Visible LEDs
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 1.99mm Lx2.21mm W
Published 2013
Packaging Tape & Reel (TR)

Physical

Shape CYLINDRICAL
Number of Pins 2
Package / Case 2-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 9 Weeks
