ASMT-SWB5-NW703
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
BROADCOM LIMITED ASMT-SWB5-NW703 LED, White, SMD, 50 mA, 3.2 V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.6028
≥100 USD $0.39512
≥500 USD $0.311969
Inventory: 37529
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 2.1mm
Technical
Reverse Voltage 5V
Lens Color Yellow
Lens Transparency Diffused
Millicandela Rating 2125mcd
Luminous Intensity 2.125 cd
Lens Size 2.20mm Dia
Lens Style Round with Flat Top
Current - Test 30mA
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 3.2V
Power Dissipation 114mW
Configuration Standard
Number of Elements 1
Base Part Number ASMT-S*B5
Depth 3.2mm
Max Power Dissipation 114mW
Power Rating 114mW
Subcategory Visible LEDs
Color White
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e3
Size / Dimension 3.20mm Lx2.80mm W
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
