ASMT-CB20

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED, SMD, 0603, BLUE
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 6184
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Supplier Device Package Chip LED
Number of Pins 2
Package / Case 0603 (1608 Metric)

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Height (Max) 0.30mm
Width 800μm
Length 1.6mm
Height 200μm

Technical

Number of LEDs 1
Wavelength - Dominant 470nm
Wavelength 475 nm
Lens Color Clear
Wavelength - Peak 468nm
Illumination Color Blue
Millicandela Rating 25mcd
Luminous Intensity 25 mcd
Forward Voltage 3.15V
Lens Size 1.60mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 10mA
Forward Current 5mA
Viewing Angle 150°
Voltage - Forward (Vf) (Typ) 2.85V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Base Part Number ASMT-CB20
Power Rating 32mW
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Size / Dimension 1.60mm Lx0.80mm W
Published 2010
Packaging Tape & Reel (TR)
