ASMT-CA00
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED, SMD, 0.4MM, R/A, AMBER
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.082065
≥1 USD $0.082065
Inventory: 72003
Minimum: 1
-
+
Technical Details
Technical
Configuration Standard
Power Dissipation 60mW
Voltage - Forward (Vf) (Typ) 1.9V
Viewing Angle 150°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Domed Top
Lens Size 1.20mmx0.50mm
Luminous Intensity 90 mcd
Illumination Color Orange
Lens Transparency Clear
Wavelength - Peak 595nm
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 592nm
Number of Elements 1
Base Part Number ASMT-C*00
Depth 600μm
Number of Functions 1
Max Power Dissipation 60mW
Packing Method TAPE AND REEL 7"
Power Rating 60mW
Subcategory Visible LEDs
Additional Feature SIDE VIEW, SUPPORTS INFRARED
Color Amber
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Size / Dimension 1.60mm Lx1.00mm W
Packaging Tape & Reel (TR)
Dimensions
Height 450μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
