SM1206UBWC
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Ultra Blue 470 nm Water Clear
PDF
/
Inventory: 3912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 1.1mm
Technical
Wavelength - Dominant 470nm
Forward Voltage-Max 4V
Lens Color Colorless
Wavelength - Peak 468nm
Lens Transparency Clear
Millicandela Rating 115mcd
Luminous Intensity 115 mcd
Lens Size 2.00mmx1.60mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.3V
Configuration Standard
Case Code (Imperial) 1206
Case Code (Metric) 3216
Reach Compliance Code unknown
Terminal Pitch 3.5mm
Number of Functions 1
Packing Method TR, 7 INCH
Power Rating 100mW
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Blue
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Size / Dimension 3.20mm Lx1.60mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
