SM1206HC-IL
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD HE Red 635 nm Water Clear
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.683189
≥1 USD $0.683189
≥10 USD $0.644521
≥100 USD $0.608041
≥500 USD $0.573615
≥1000 USD $0.541147
Inventory: 8746
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 3.20mm Lx1.60mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Color Red
HTS Code 8541.40.20.00
Power Rating 78mW
Reach Compliance Code unknown
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 140°
Forward Current 20mA
Lens Style Round with Flat Top
Lens Size 1.10mm Dia
Luminous Intensity 45 mcd
Millicandela Rating 45mcd
Lens Transparency Clear
Wavelength - Peak 660nm
Lens Color Colorless
Wavelength - Dominant 643nm
Dimensions
Height 1.4mm
Compliance
RoHS Status ROHS3 Compliant
