TLD1020-24
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
TRIAD MAGNETICS TLD1020-24 LED DRIVER, AC-DC, CV, 24V, 40W
PDF
/
Buying Options
Total Price: USD $30.36
Unit Price: USD $30.36
≥1 USD $30.36
≥10 USD $28.7584
≥100 USD $27.1612
≥500 USD $25.963168
≥1000 USD $24.764784
≥3000 USD $23.96592
Inventory: 1073
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case 100
Number of Pins 4
Weight 0.265lb 120.2g
Technical
Operating Temperature -30°C~60°C
Published 2012
Series TLD1020
Size / Dimension 3.74Lx1.57W x 0.98 H 95.0mmx40.0mmx25.0mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
Type Constant Voltage
Max Operating Temperature 60°C
Min Operating Temperature -30°C
Power (Watts) 20W
Power Rating 20W
Max Power Dissipation 20W
Termination Style Wire Leads
Number of Outputs 1
Approval Agency CE, cUL, UL
Efficiency 84%
Voltage - Input (Max) 304VAC
Max Output Current 830mA
Voltage - Output 1 24V
Voltage - Input (Min) 100VAC
Current - Output (Max) 830mA
Output Current 830mA
Output Power 20W
Max Output Voltage 24V
Voltage - Output 24V
Topology AC DC Converter
Min Input Voltage 90V
Max Input Voltage 264V
Current - Output 1 830mA
Max Output Power 40W
Dimensions
Height 24.892mm
Length 94.996mm
Width 39.878mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings IP66, NEMA 4
